Tandem Tankers
Precision and Power
Abbey Machinery’s Tandem and Tandem Recess Tankers redefine the standards of efficiency and precision in slurry management. Spanning six models in the Tandem range and four in the Tandem Recess range, these tankers are engineered to cater to extensive agricultural demands, with tank sizes ranging from 13,850L (3,000 gal) to 20,760L (4,500 gal). Equipped with self-steering Bogie systems, Parabolic Weight Sensing Sprung Drawbars, and state-of-the-art MEC 11,000 pumps, these tankers are designed for both efficiency and comfort. Our range ensure reduced soil compaction and enhanced manoeuvrability, making them the ideal choice for large-scale agricultural operations seeking reliability and precision.
Technical Specification
3000 Tandem Tanker
| Model | 3000T |
| Approx. Capacity (gl) | 3000 |
| Litre Capacity (L) | 13,850 |
| Dished End Size (inch) | 72 |
| Barrel Length (m) | 5.63 |
| Overall Width (mm) | 2912 |
| Approx. Overall Height (mm) (18” hook) | 3423 |
| Overall Length Without Splash Plate (mm) | 7628 |
| Pump Capacity (L/min) | 11,000 |
| Standard Hose Length (m) | 6.10 |
| Back Door Size (inch) | 24 |
| Unladen Weight (kg) | 6760 |
| Wheel Size as Standard | 710/50 R26.5 |
Features
- Self Steer Bogie System
- Parabolic Weight Sensing Sprung Drawbar
- MEC 11,000 Pump
- Hydraulic 420 x 180 Brakes with 150sq Axle
- Dynamic Lights
- Side Amber Lights
- Power Brake System
- 24″ Door
- Rear Hydraulically Operated Heavy Duty Outlet Valve
- Inverted Spreading Plate
- One Blank Fill Point with 2″ Wash Tap
- Two Complete Quick Attach Fill Points
- One Front Blank Point
- 20ft of 6″ Suction Hose
- Lights on Front Mudguards
- Stone Trap
- Air Brake Ready
- Auto Slack Adjuster
- Bolt-On Ring Hitch
- Band Spreader & Agri Pro Ready Bracketry
- With 710/50 R26.5 Wheels
3500 Tandem Tanker
| Model | 3500T |
| Approx. Capacity (gl) | 3500 |
| Litre Capacity (L) | 15,750 |
| Dished End Size (inch) | 72 |
| Barrel Length (m) | 5.44 |
| Overall Width (mm) | 2912 |
| Approx. Overall Height (mm) (18” hook) | 3360 |
| Overall Length Without Splash Plate (mm) | 8380 |
| Pump Capacity (L/min) | 11,000 |
| Standard Hose Length (m) | 6.10 |
| Back Door Size (inch) | 24 |
| Unladen Weight (kg) | 7000 |
| Wheel Size as Standard | 710/50 R26.5 |
Features
- Self Steer Bogie System
- Parabolic Weight Sensing Sprung Drawbar
- MEC 11,000 Pump
- Hydraulic 420 x 180 Brakes with 150sq Axle
- Dynamic Lights
- Side Amber Lights
- Lights on Front Mudguards
- Power Brake System
- 24″ Door
- Rear Hydraulically Operated Heavy Duty Outlet Valve
- Inverted Spreading Plate
- One Blank Fill Point with 2″ Wash Tap
- Two Complete Quick Attach Fill Points
- One Front Blank Point
- Bolt-On Galvanised Mudguards
- 20ft of 6″ Suction Hose
- Stone Trap
- Bolt On Ring Hitch
- Auto Slack Adjuster
- Band Spreader & Agri Pro Ready Bracketry
- With 710/50 R26.5 Wheels
4000 Tandem Tanker
| Model | 4000T |
| Approx. Capacity (gl) | 4500 |
| Litre Capacity (L) | 18,240 |
| Dished End Size (inch) | 78 |
| Barrel Length (m) | 6.27 |
| Overall Width (mm) | 2912 |
| Approx. Overall Height (mm) (18” hook) | 3596 |
| Overall Length Without Splash Plate (mm) | 8415 |
| Pump Capacity (L/min) | 11,000 |
| Standard Hose Length (m) | 6.10 |
| Back Door Size (inch) | 24 |
| Unladen Weight (kg) | 7320 |
| Wheel Size as Standard | 710/50 R26.5 |
Features
- Self Steering Bogie System
- Parabolic Weight Sensing Sprung Drawbar
- MEC 11,000 Pump
- Hydraulic 420 x 180 Brakes with 150sq Axle
- Dynamic Lights
- 24” Door
- Rear Hydraulically Operated Heavy Duty Outlet Valve
- Inverted Spreading Plate
- One Blank Fill Point with 2” Wash Tap
- Two Complete Quick Attach Fill Points
- One Front Blank Point
- 20ft of 6” Suction Hose
- Stone Trap
- Auto Slack Adjuster
- Bolt-On Ring Hitch
- Bolt-On Galvanised Mudguards
- Band Spreader Ready Bracketry
- With 710/50 R26.5 Wheels
4500 Tandem Tanker
| Model | 4500T |
| Approx. Capacity (gl) | 4500 |
| Litre Capacity (L) | 20,760 |
| Dished End Size (inch) | 78 |
| Barrel Length (m) | 7.11 |
| Overall Width (mm) | 2912 |
| Approx. Overall Height (mm) (18” hook) | 3583 |
| Overall Length Without Splash Plate (mm) | 9256 |
| Pump Capacity (L/min) | 11,000 |
| Standard Hose Length (m) | 6.10 |
| Back Door Size (inch) | 24 |
| Unladen Weight (kg) | 8100 |
| Wheel Size as Standard | 710/50 R26.5 |
Features
- Self Steer Bogie System
- MEC 11,000 Pump
- Parabolic Weight Sensing Sprung Drawbar
- Hydraulic 420 x 180 Brakes with 150sq Axle
- Dynamic Lights
- Side Amber Lights
- 24″ Door
- Rear Hydraulically Operated Heavy Duty Outlet Valve
- Inverted Spreading Plate
- One Blank Fill Point with 2″ Wash Tap
- Two Complete Quick Attach Fill Points
- One Front Blank Point
- Bolt-On Galvanised Mudguards
- 20ft of 6″ Suction Hose
- Lights on Front Mudguards
- Stone Trap
- Auto Slack Adjuster
- Bolt-On Ring Hitch
- Band Spreader & Agri Pro Ready Bracketry
- With 710/50 R26.5 Wheels
3000 Recess Tandem Tanker
| Model | 3000RT |
| Approx. Capacity (gl) | 3000 |
| Litre Capacity (L) | 13,990 |
| Dished End Size (inch) | 72 |
| Barrel Length (m) | 5.79 |
| Overall Width (mm) | 2773 |
| Approx. Overall Height (mm) (18” hook) | 3335 |
| Overall Length Without Splash Plate (mm) | 7798 |
| Pump Capacity (L/min) | 11,000 |
| Standard Hose Length (m) | 6.10 |
| Back Door Size (inch) | 24 |
| Unladen Weight (kg) | 6950 |
| Wheel Size as Standard | 710/50 R26.5 |
Features
- Self Steer Bogie System
- MEC 11,000 Pump
- Parabolic Weight Sensing Sprung Drawbar
- Hydraulic 420 x 180 Brakes with 150sq Axle
- Dynamic Lights
- Side Amber Lights
- Power Brake System
- 24″ Door
- Rear Hydraulically Operated Heavy Duty Outlet Valve
- Inverted Spreading Plate
- One Blank Fill Point with 2″ Wash Tap
- Two Complete Quick Attach Fill Points
- One Front Blank Point
- Bolt-On Galvanised Mudguards
- 20ft of 6″ Suction Hose
- Lights on Front Mudguards
- Stone Trap
- Auto Slack Adjuster
- Bolt-On Ring Hitch
- Band Spreader & Agri Pro Ready Bracketry
- With 710/50 R26.5 Wheels
3500 Recess Tandem Tanker
| Model | 3500RT |
| Approx. Capacity (gl) | 3300 |
| Litre Capacity (L) | 15,820 |
| Dished End Size (inch) | 72 |
| Barrel Length (m) | 5.69 |
| Overall Width (mm) | 2773 |
| Approx. Overall Height (mm) (18” hook) | 3496 |
| Overall Length Without Splash Plate (mm) | 8543 |
| Pump Capacity (L/min) | 11,000 |
| Standard Hose Length (m) | 6.10 |
| Back Door Size (inch) | 24 |
| Unladen Weight (kg) | 7300 |
| Wheel Size as Standard | 710/50 R26.5 |
Features
- Self Steer Bogie System
- MEC 11,000 Pump
- Parabolic Weight Sensing Sprung Drawbar
- Hydraulic 420 x 180 Brakes with 150sq Axle
- Dynamic Lights
- Side Amber Lights
- 24″ Door
- Rear Hydraulically Operated Heavy Duty Outlet Valve
- Inverted Spreading Plate
- One Blank Fill Point with 2″ Wash Tap
- Two Complete Quick Attach Fill Points
- One Front Blank Point
- Bolt-On Galvanised Mudguards
- 20ft of 6″ Suction Hose
- Lights on Front Mudguards
- Stone Trap
- Auto Slack Adjuster
- Bolt-On Ring Hitch
- Power Brake System
- Band Spreader & Agri Pro Ready Bracketry
- With 710/50 R26.5 Wheels
4000 Recess Tandem Tanker
| Model | 4000RT |
| Approx. Capacity (gl) | 3800 |
| Litre Capacity (L) | 18,070 |
| Dished End Size (inch) | 78 |
| Barrel Length (m) | 6.44 |
| Overall Width (mm) | 2773 |
| Approx. Overall Height (mm) (18” hook) | 3497 |
| Overall Length Without Splash Plate (mm) | 8570 |
| Pump Capacity (L/min) | 11,000 |
| Standard Hose Length (m) | 6.10 |
| Back Door Size (inch) | 24 |
| Unladen Weight (kg) | 7720 |
| Wheel Size as Standard | 710/50 R26.5 |
Features
- Self Steer Bogie System
- MEC 11,000 Pump
- Parabolic Weight Sensing Sprung Drawbar
- Hydraulic 420 x 180 Brakes with 150sq Axle
- Dynamic Lights
- Side Amber Lights
- 24″ Door
- Rear Hydraulically Operated Heavy Duty Outlet Valve
- Inverted Spreading Plate
- One Blank Fill Point with 2″ Wash Tap
- Two Complete Quick Attach Fill Points
- One Front Blank Point
- Bolt-On Galvanised Mudguards
- 20ft of 6″ Suction Hose
- Lights on Front Mudguards
- Stone Trap
- Auto Slack Adjuster
- Bolt-On Ring Hitch
- Power Brake System
- Band Spreader & Agri Pro Ready Bracketry
- With 710/50 R26.5 Wheels
4500 Recess Tandem Tanker
| Model | 4500RT |
| Approx. Capacity (gl) | 4500 |
| Litre Capacity (L) | 20,580 |
| Dished End Size (inch) | 78 |
| Barrel Length (m) | 7.28 |
| Overall Width (mm) | 2773 |
| Approx. Overall Height (mm) (18” hook) | 3500 |
| Overall Length Without Splash Plate (mm) | 9406 |
| Pump Capacity (L/min) | 11,000 |
| Standard Hose Length (m) | 6.10 |
| Back Door Size (inch) | 24 |
| Unladen Weight (kg) | 8800 |
| Wheel Size as Standard | 710/50 R26.5 |
Features
- Self Steer Bogie System
- MEC 11,000 Pump
- Parabolic Weight Sensing Sprung Drawbar
- Hydraulic 420 x 180 Brakes with 150sq Axle
- Dynamic Lights
- Side Amber Lights
- 24″ Door
- Rear Hydraulically Operated Heavy Duty Outlet Valve
- Inverted Spreading Plate
- One Blank Fill Point with 2″ Wash Tap
- Two Complete Quick Attach Fill Points
- One Front Blank Point
- Bolt-On Galvanised Mudguards
- 20ft of 6″ Suction Hose
- Lights on Front Mudguards
- Stone Trap
- Auto Slack Adjuster
- Power Brake System
- Bolt-On Ring Hitch
- Band Spreader & Agri Pro Ready Bracketry
- With 710/50 R26.5 Wheels
